DIGI-107 Polarizing Microscope

A polarizing microscope uses polarized light to examine anisotropic materials. It enhances contrast by rotating polarized light through the sample, revealing properties like crystal structure and birefringence, ideal for geology, mineralogy, and material science studies.



Features
With the features of easy operation, complete functions and economy, it is ideal instrument in geology, petroleum, coal, chemicals and physic fields, It is also widely used in academic demonstration and research.
  •  Easy Operation
  •  Complete functions and economy
  •  Petroleum, coal, chemicals and physic fields
Specification
Monocular Head inclined at 45, Sliding binocular head inclined at 45,Sliding trinocular head inclined at 45,Eyepiecs WF10X18 with Scale of Crosshair,WF10X18,Strain free achromatic objective 4X, 10X, 40X, Toward quadruple nosepiece
  • Monocular Head inclined at 45, Sliding binocular head inclined at 45, Sliding trinocular head inclined at 45
  • Eyepiecs WF10X18 with Scale of Crosshair, WF10X18
  • Strain free achromatic objective 4X, 10X, 40X
  • Rotatable analyzer with graduation 0 -90
  • Optical Compensator, 1/4 Slip Quartz Wedge
Revolving Round Stage
Diameter 135mm, 360 Rotatable and graduate in 1 Increments, Minimum resolution 6' When using venire scale, Center adjustable.
  • Abbe Condenser NA 1.25with Iris diaphragm & Filter.
  • Coaxial coarse & fine adjustment, range 28mm, fine division 0.002.
  • Sliding in/out of optical path, Located on the top of collector
  • 6V/20W Halogen lamp, Brightness adjustable
